Triad Magnetics VPT24-10420

Part No.:
VPT24-10420
Manufacturer:
Triad Magnetics
Category:
Power Transformers
Package:
Datasheet:
IC Supply HubVPT24-10420.pdf
Description:
PWR XFMR TOROIDAL 250VA CHAS MT
Quantity:
Payment:
Payment
Shipping:
Shipping

Inventory:46

Please send an inquiry. Send us your inquiry, and we will respond immediately.

Part Number
Quantity
Price
Name
Company
Email
Comments
  • Specifications
  • FAQ
  • Product Comparison
  • Tags
Product attributes
Attribute value
Manufacturer:
Triad Magnetics
Series:
Chassis Mount: World Series™
Packaging:
Box
Product Status:
Active
Type:
Toroidal
Voltage - Primary:
115V, 230V
Voltage - Secondary (Full Load):
Parallel 12V, Series 24V
Current - Output (Max):
Parallel 20.84A, Series 10.42A
Primary Winding(s):
Dual
Secondary Winding(s):
Dual
Center Tap:
No
Power - Max:
250VA
Mounting Type:
Chassis Mount
Termination Style:
Wire Leads
Size / Dimension:
112.00mm Dia x 54.00mm W
Height - Seated (Max):
58.0mm
Voltage - Isolation:
4000Vrms
Weight:
4.9 lbs (2.2 kg)
