Pulse Electronics PE-51688NL

Part No.:
PE-51688NL
Manufacturer:
Pulse Electronics
Category:
Current Sense Transformers
Package:
Datasheet:
IC Supply HubPE-51688NL.pdf
Description:
CURR SENSE XFMR 20A T/H
Quantity:
Payment:
Payment
Shipping:
Shipping

Inventory:926

Please send an inquiry. Send us your inquiry, and we will respond immediately.

Part Number
Quantity
Price
Name
Company
Email
Comments
  • Specifications
  • FAQ
  • Product Comparison
  • Tags
Product attributes
Attribute value
Manufacturer:
Pulse Electronics
Series:
THT
Packaging:
Tray
Product Status:
Active
Frequency Range:
20kHz ~ 200kHz
Type:
Invasive
Current Rating (Amps):
20 A
Inductance:
80 mH
ET (Volt-Time):
-
Turns Ratio - Primary:Secondary:
-
Current Ratio:
200:1
DC Resistance (DCR):
200Ohm Primary, 4.5Ohm Secondary
Ratings:
-
Mounting Type:
Through Hole
Size / Dimension:
0.670" L x 0.390" W (17.01mm x 9.90mm)
Height - Seated (Max):
0.800" (20.32mm)
Termination Style:
PC Pin
