Pulse Electronics P0403NL

Part No.:
P0403NL
Manufacturer:
Pulse Electronics
Category:
Arrays, Signal Transformers
Package:
Nonstandard
Datasheet:
IC Supply HubP0403NL.pdf
Description:
INDUCT ARRAY 2 COIL 50.5UH SMD
Quantity:
Payment:
Payment
Shipping:
Shipping

Inventory:115

Please send an inquiry. Send us your inquiry, and we will respond immediately.

Part Number
Quantity
Price
Name
Company
Email
Comments
  • Specifications
  • FAQ
  • Product Comparison
  • Tags
Product attributes
Attribute value
Manufacturer:
Pulse Electronics
Series:
Tomcat
Package/Case:
Nonstandard
Packaging:
Tube
Product Status:
Active
Number of Coils:
2
Inductance - Connected In Parallel:
50.5 µH
Inductance - Connected In Series:
202.2 µH
Tolerance:
±20%
Current Rating - Parallel:
3 A
Current Rating - Series:
1.5 A
Current Saturation - Parallel:
-
Current Saturation - Series:
-
DC Resistance (DCR) - Parallel:
73.89mOhm
DC Resistance (DCR) - Series:
295.6mOhm
Shielding:
Unshielded
Ratings:
-
Operating Temperature:
-40°C ~ 130°C
Mounting Type:
Surface Mount
Size / Dimension:
0.715" L x 0.590" W (18.16mm x 14.99mm)
Height:
0.310" (7.87mm)

1. How to order P0403NL on IC Supply Hub?

Currently, IC Supply Hub only provide peer-to-peer order processing. While you submit the RFQ, our professional agent will contact you with the competitive prices in the global market, and our agent will prompt you to finish the order if you accept our offers.

2. How does IC Supply Hub guarantee that P0403NL is from the original manufacturer or authorized agents?

We have a professional and experienced quality control team to strictly verify and test the P0403NL. All suppliers must pass our qualification reviews before they can publish their products including P0403NL on IC Supply Hub; we pay more attention to the channels and quality of P0403NL products than any other customer. We strictly implement supplier audits, so you can purchase with confidence.

3. Are the P0403NL price and inventory displayed accurate?

The price and inventory of P0403NL fluctuates frequently and cannot be updated in time, it will be updated periodically within 24 hours. And, our quotation usually expires after 5 days.

4. What forms of payment are accepted?

Wire Transfer, PayPal, Alipay, Wechat, Credit Card, Western Union, MoneyGram, and Escrow are all acceptable.

Warm Tips: Some orders in certain payment forms may require handling fee.

5. How is the shipping arranged?

Customers can choose industry-leading freight companies, including DHL, UPS, FedEx, TNT, and Registered Mail. Shipping insurance is also available.

Once your order has been processed for shipment, our salesperson will send you an email advising you of the shipping status and tracking number.

Warm Tips: It may take up to 24 hours for the carriers to display tracking information. Usually, express delivery takes 3-5 days, and registered mail takes 25-60 days.

6. What is the process for return or replacement of P0403NL?

All goods will implement Pre-Shipment Inspection (PSI), selected at random from all batches of your order to do a systematic inspection before arranging the shipment. If there is something wrong with the P0403NL we delivered, we will accept the replacement or return of the P0403NL only when all of the below conditions are fulfilled:

(1)Such as a deficiency in quantity, delivery of wrong items, and apparent external defects (breakage and rust, etc.), and we acknowledge such problems.

(2)We are informed of the defect described above within 90 days after the delivery of P0403NL.

(3)The PartNo is unused and only in the original unpacked packaging.

Two processes to return the products:

(1)Inform us within 90 days

(2)Obtain Requesting Return Authorizations

7.How to contact us to get technical supports, such as P0403NL pin diagram, P0403NL datasheet?

If you need any after-sales service, please do not hesitate to contact us.

Image P0403NL P0403NLT
Part Number P0403NL P0403NLT
Manufacturer Pulse Electronics Pulse Electronics
Series Tomcat Tomcat
Package/Case Nonstandard Nonstandard
Packaging Tube Tape & Reel (TR)
Product Status Active Active
Number of Coils 2 2
Inductance - Connected In Parallel 50.5 µH 50.5 µH
Inductance - Connected In Series 202.2 µH 202.2 µH
Tolerance ±20% ±20%
Current Rating - Parallel 3 A 3 A
Current Rating - Series 1.5 A 1.5 A
Current Saturation - Parallel - -
Current Saturation - Series - -
DC Resistance (DCR) - Parallel 73.89mOhm 73.89mOhm
DC Resistance (DCR) - Series 295.6mOhm 295.6mOhm
Shielding Unshielded Unshielded
Ratings - -
Operating Temperature -40°C ~ 130°C -40°C ~ 130°C
Mounting Type Surface Mount Surface Mount
Size / Dimension 0.715" L x 0.590" W (18.16mm x 14.99mm) 0.715" L x 0.590" W (18.16mm x 14.99mm)
Height 0.310" (7.87mm) 0.310" (7.87mm)
