onsemi NCP1568S02DBR2G

Part No.:
NCP1568S02DBR2G
Manufacturer:
onsemi
Category:
AC DC Converters, Offline Switches
Package:
16-TSSOP (0.173", 4.40mm Width), 12 Leads
Datasheet:
IC Supply HubNCP1568S02DBR2G.pdf
Description:
IC OFFLINE SW FLYBACK 16TSSOP
Quantity:
Payment:
Payment
Shipping:
Shipping

Inventory:2,428

Please send an inquiry. Send us your inquiry, and we will respond immediately.

Part Number
Quantity
Price
Name
Company
Email
Comments
  • Specifications
  • FAQ
  • Product Comparison
  • Tags
Product attributes
Attribute value
Manufacturer:
onsemi
Series:
-
Package/Case:
16-TSSOP (0.173", 4.40mm Width), 12 Leads
Packaging:
Tape & Reel (TR)
Product Status:
Active
Output Isolation:
Isolated
Internal Switch(s):
Yes
Voltage - Breakdown:
-
Topology:
Flyback
Voltage - Start Up:
15.2 V
Voltage - Supply (Vcc/Vdd):
10V ~ 27V
Duty Cycle:
79%
Frequency - Switching:
100kHz ~ 1MHz
Power (Watts):
-
Fault Protection:
Current Limiting, Over Power, Over Temperature, Over Voltage, Short Circuit
Control Features:
Frequency Control, Soft Start
Operating Temperature:
-40°C ~ 125°C (TJ)
Grade:
-
Qualification:
-
Supplier Device Package:
16-TSSOP
Mounting Type:
Surface Mount
