Nexperia USA Inc. BAT54S,215

Part No.:
BAT54S,215
Manufacturer:
Nexperia USA Inc.
Category:
Diode Arrays
Package:
TO-236-3, SC-59, SOT-23-3
Datasheet:
IC Supply HubBAT54S,215.pdf
Description:
DIODE ARR SCHOTTKY 30V TO-236AB
Quantity:
Payment:
Payment
Shipping:
Shipping

Inventory:1,183,781

Please send an inquiry. Send us your inquiry, and we will respond immediately.

Part Number
Quantity
Price
Name
Company
Email
Comments
  • Specifications
  • FAQ
  • Product Comparison
  • Tags
Product attributes
Attribute value
Manufacturer:
Nexperia USA Inc.
Series:
-
Package/Case:
TO-236-3, SC-59, SOT-23-3
Packaging:
Tape & Reel (TR)
Product Status:
Active
Diode Configuration:
1 Pair Series Connection
Technology:
Schottky
Voltage - DC Reverse (Vr) (Max):
30 V
Current - Average Rectified (Io) (per Diode):
200mA (DC)
Voltage - Forward (Vf) (Max) @ If:
800 mV @ 100 mA
Speed:
Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr):
5 ns
Current - Reverse Leakage @ Vr:
2 µA @ 25 V
Operating Temperature - Junction:
150°C (Max)
Grade:
Automotive
Qualification:
AEC-Q101
Mounting Type:
Surface Mount
Supplier Device Package:
TO-236AB
